Thermallyformed Polyester Single Button Membrane Switch For Test Device

Name: Thermallyformed Polyester Single Button Membrane Switch For Test Device
Brand: Taida
Price: 1 USD

Brand Name : Taida

Model Number : 20250508-03

Certification : ISO9001,SGS,ROHS,REACH,UL

Place of Origin : DongGuan of China

MOQ : 100 pcs

Price : communication

Payment Terms : Western Union, T/T,PAYPAL

Supply Ability : 75000 +pcs +a Month

Delivery Time : 4-5 days for Samples making ;10-15 days for Batch goods

Packaging Details : PE bags first and Foam in Carton and etc

Material : Polyester or Polycarbonate ,silicone or other

Color : Pantone, RAL CMYK ,RGB or samples

Pitch of Connect : 1.0MM ,1.25MM，2.54MM，or 0.5MM

Adhesive : 3M467 adheisve or others

Button type : Embossing metal dome

Connector type : ZIF connector

circuit options : FPC circuit

Appition : Test device

Contact Now

Thermallyformed Polyester Single Button Membrane Switch For Test Device

A single button membrane switch is a type of user interface device that consists of a flat membrane with a single button that, when pressed, completes a circuit to activate a function. These switches are commonly used in a variety of electronic devices due to their durability, low profile, and ease of integration.

Key Features:

Thin Profile: Membrane switches are often very thin, making them suitable for compact designs.
Sealed Design: They are usually sealed against dust and moisture, enhancing durability.
Customizable: Graphics and labeling can be printed directly on the surface.
Tactile Feedback: Some designs offer tactile feedback to indicate activation.

Applications:

Consumer electronics (e.g., remote controls, appliances)
Industrial equipment
Medical devices

Membrane keyboard foil Specification:

Overlay material ---For front or face overlay
Polyester						Polycarbonate
1 Highly versatile for embossing 2 Highly resistant for chemicals 3 Better durability						1 wide range of the surface finishes and thicknesses 2 More cost-effective
Embossing --- Graphic overlay or up circuit can be embossed in order to insert metal stainless steel domes for good tactile when press .
Pedestal embossing	Rim embossing		Pillow embossing				Dim embossing
Windows or LCD --- For display functions
Printed colors windows such like red ,black and so on					Transparent finishes windows
Keys
Tactile Keys :witch metal domes or Poly domes ,Metal dome with different diameter and pressure kinds					Non-tactile keys: printed silver spot on the circuit
LEDs ---Miniature LEDs ,LED colors :white ,Green ,Red ,Blue ,Yellow ,Orange and others
EL and Sensors or inductors --- EL can be light any place where where you like ,and sensors can be used as LEDs
Cables --- is extension of circuit and communication with your device
Screen printing conductive silver cable		Copper plated cable /Polyimide or FPC						PCB cable
Types of connector --- 1 Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch ;2 Female connector with 2.54MM pitch; 3 Male connector
Shielding --- For protection function
Gasket seal/Waterproof :protect the conductors against from the humidity and splashes				EMI/RFI/ESD Shielding: use an Aluminum foil shielding /clear ITO electrical conductive polyester to protect
Rear Adhesive --- Mostly use the 3M double-side mounting glue brand of USA. Also accepted others such like Lohmann and others
Back plate --- Use in Aluminum ,Polycarbonate ,Acrylic Or PMMA
Matching color --- PMS or RAL Is best ,CMYK or RGB also can be ok if you can supply PMS Or RAL
Standard Tolerances :+/-0.2MM

Performance Index

Environmentl	Operating Temperature	-40°C to +80°C (-40°to 176°F)
	Storage Temperature	-40°C to +85°C (-40°to 185°F)
	Humidity	40°C, 90% to 95% for 240 hours
	Vibration	20G's max.
Mechanical	Actuation Force	Non-tactile 60g to 300g (2oz to 10oz)
		Tactile 150g to 400g (6oz to 14oz)
	Switch Stroke	Non-tactile 0.1 to 0.5mm
	Life Expectancy	Tactile 0.6 to 1.5mm
		Non-tactile >5 million actuations
		Tactile >1 million actuations

About Taida.pdf

More photos show :

FAQ:
Q1. What information will I have to provide for price?
A:To offer the exact price, we hope customers could inform us the material, specification as thickness, size, with adhesive or not, how many colors for printings, contact details, quantity required, Size and Shape with artwork files.
Q2. What is your terms of payment?
A:T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. How about your delivery time?
A: After the engineering drawing is confirmed, the sample will be completed in 5 days, and after the sample is confirmed, the mass goods will be completed in 10 days.The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
